CS2P11-203 (E) L
Specifications | inch |
---|---|
Unit Number | CS2P11-203L |
Bearing Number | 22211-203CSL |
Shaft Size | 2 3/16 |
Bolt Size | 5/8 |
Bolt / Torque | 735 in-lbs |
Locking Style | Setscrew |
Setscrew | 7/16-20UNF |
Setscrew / Torque | 269 in-lbs |
Grease Fitting | A-NPT1/8 |
Grease | Fuchs Renolit LX-TAC2 |
Weight | 11.22 lbs |
Dimensions | inch |
H | 2 1/2 |
L | 8 1/2 |
A | 2 5/8 |
J | 6 3/4 |
N | 25/32 |
N1 | 31/32 |
H1 | 1 1/2 |
H2 | 4 31/32 |
V | 1 |
A0 | 3 5/16 |
B | 3 |
Basic Load Ratings | lbf |
Cr | 27450 |
Cor | 32625 |
